Reliable Data-Logger DL-04 - Manual (Page 32)

Reliable Scale Corporation
Model DL-04 DATA-LOGGER
User Manual Page 32 of 38 Rev. 1.70
5.5 Plot Delay
In order to allow the printer to keep up with the data transfer, a time
delay is used. After each line of the chart has been transferred, the
DL-
04 waits for a specific amount of time. This length of time is
determined by the Plot Delay setting and is measured in milliseconds.
1. From the Configuration Menu, select
Plot Delay.
CONFIGURATION MENU
5 Plot Delay
6 Set Password
Select # more: S
2. The current Plot Delay setting is
displayed and the user in prompted for
the new setting.
SET DELAY
Current Delay: 1100
New Delay: „
F4 : Quit
3. Key in the new Port Delay setting.
Example: 1500mS
SET DELAY
Current Delay: 1100
New Delay: 1500„
F4 : Quit
SET DELAY
Plot Delay: 1500mS
4. To quit, press F4 .
