Screen shows first port functions. use the, Arrow keys to scroll through the list, Down – Reliable Data-Logger DL-04 User Manual
Page 24: Port functions pc port: 1 counter port: 2, Quit more, Port functions weight port 3 printer port 1
Reliable Scale Corporation
Model DL-04 DATA-LOGGER
User Manual
Page 24 of 38
Rev. 1.70
5.3.1 Show Port Function
The current port assignments can be seen by using the Show Port
Function option in the Port Config Menu. This can be a useful
troubleshooting tool if device communications problems arise.
1. From the Port Config Menu, select
Show Port Function
PORT CONFIG MENU
1 Show Port Function
2 Set Port Function
Select # more:
S
2. Screen shows first Port Functions. Use
the
UP
and
DOWN
arrow keys to scroll
through the list.
PORT FUNCTIONS
PC Port: 1
Counter Port: 2
F4
: Quit more:
S
PORT FUNCTIONS
Weight Port 3
Printer Port 1
F4
: Quit more:
S
3. To quit, press
F4
.
