(2) Connecting the Cable to the Emulation Pod
Figure 3.10 shows how to connect the FLX120-RPD and the emulation pod.
Figure 3.10 Connecting FLX120-RPD and emulation pod
CAUTION
Note on Connecting the Cable:
• Always shut OFF power before connecting the FLX120-RPD. The power ON state
could destroy internal circuits.
Note on Securing the Screws:
• After connecting the FLX120-RPD to the emulation pod, be sure to secure the
screws.
