2.2 Package Components
The M30240T-RPD-E package consists of the following items. When unpacking, check to see if your
package contains all of these items.
Please keep the M30240T-RPD-E’s packing box and cushion material in your place for reuse at a later
time when sending your product for repair or other purposes. Always use these packing box and
cushion material when transporting this product.
If any of these items are missing or found faulty, please contact your local distributor. Also, if there
is any question or doubt about the packaged product, contact your local distributor.
2.3 Other Tool Products Required for Development
To bring forward programs development on the M30240 Group MCUs, the products listed below are
necessary in addition to those contained package above. Get them separately.
To purchase these products, contact your nearest distributer.
Item
M30240T-RPD-E emulation pod main unit
FLX120-RPD flexible cable for connecting PC4701
FLX-80LCC pitch converter board for 80-pin 0.8mm-pitch LCC
OSC-2 (12MHz) oscillator circuit board (pre-installed in emulation pod)
OSC-2 oscillator circuit board (bare-board, connector pins mounted)
Hardware tool user registration FAX sheet (English)
Hardware tool user registration FAX sheet (Japanese)
M30240T-RPD-E user's manual (this manual)
M30240T-RPD-E user's manual (Japanese)
Quantity
1
1
1
1
1
1
1
1
1
Emulator main unit
Emulator debugger
PROM programming adapter
PC4701M, PC4701HS or PC4701L
M3T-PD30 (Ver.4.00 or greater)
PCA7302E1F-80 for 80-pin QFP
(necessary to write into MCUs with internal PROM)
PCA7302E1L-80 for 80-pin LCC
(necessary to write into MCUs with internal PROM)
