Raynger 3i Series Operator’s Manual E-1
APPENDIX E: TRACEABILITY OF INSTRUMENT CALIBRATION
The temperature sources (blackbodies) used to calibrate this instrument are traceable
to the U.S. National Institute of Standards and Technology (NIST).
The calibration sources for this instrument were certified by a NIST certified calibra-
tion laboratory and are traceable to NIST primary standards. The certificate describes
the equipment used for calibration and any corresponding NIST report numbers. In
addition, the certificate lists test accuracy data and the next calibration date.
NIST certificates are available as an option (must be ordered with the instrument).
Contact the manufacturer (not NIST) to order this option
.
Figure E-1: Traceability Flowchart
National Institute of Standards and Technology
(NIST)
NIST Certified Calibration Lab: calibration in
accordance with MIL-STD-45662 and against
standards traceable to NIST
High Temperature Models
1200 - 3000
°
C (2200 - 5400
°
F)
Certified Radiation Transfer
Standard
Medium Temperature Models
200 - 1200
°
C (400 - 2200
°
F)
Certified RTD
Instrumentation & NIST
Calibrated Radiation Transfer
Standard Instrument
Low Temperature Models
-18 - 870
°
C (0 - 1600
°
F)
Certified RTD
Instrumentation
Calibration Source
(Blackbody)
Emissivity 1.0
Calibration Source
(Blackbody)
Emissivity < 1
Measured
Source
Emissivity
Calibrated Product
Manufacturer
