Rosen Entertainment Systems 7002 - Manual (Page 20)

Rosen Aviation
Document Number: 100923 Revision: D
Date: 6/8/09
Template: 4.2.3-6-FM; Revision A; 16 May, 2005 Page 20 of 21
6.3. Technical Support
If you need assistance with an installation, please contact Rosen Aviation at 541.342.3802 or
888.668.4955.
6.4. Specifications
Table 4 7002 display specifications
Size 7” diagonal, 16 : 9 format
Resolution 800 x 480
Viewing Angle (U/D/L/R) 40/60/60/60
Brightness 400 cd/m
2
Contrast Ratio 300 : 1
Video Input 1Vp-p, 75 ohms
Video Standards NTSC, PAL, SECAM
Graphics Standards WVGA
Weight 1.4 lbs [0.6350 kg] (monitor only)
Dimensions 7” (W) x 5” (H) x 1” (D)
[17.78 cm (W) x 12.7 cm (H) x 2.54 cm (D)]
Power Requirements 28V DC
Operating Temperature 0ºC - 50ºC
Warranty 2 year
7. DEFINITIONS
DC Direct Current – voltage from an aircraft battery or generator.
GND Ground
IR Infrared
LCD Liquid crystal display
LED Light emitting diode
NTSC North American Television Standards Committee – the analog video
specification used in North American countries
OSD On screen display – a menu of user options
PAL Phase alternate (by) line – the analog video specification used by most
European countries and their former colonies world wide
PCB Printed circuit board – an electronics assembly that performs tasks
PS2 Personal system 2 (trademarked IBM keyboard specification)
RS-232 Standard for transmitting serial information using single-ended signaling
(data lines referenced to ground).
RGB Red, green, blue. An abbreviation commonly used for analog computer
graphics video that transmits the three primary colors on separate wires.
