RAD Data comm T1 - Manual (Page 20)

Chapter 1 Introduction FOM-E1/T1 Installation and Operation Manual
1-6 Technical Specifications
Physical Height 44 mm / 1.7 in (1U)
Width 179 mm / 7.0 in
Depth 203 mm / 8.0 in
Weight 1.1 kg / 3.0 lb
Power AC Voltage 115 or 230 VAC (±10%), 50 or 60 Hz, 6W
DC Voltage 24 VDC (18 to 36 VDC) or
-48 VDC (-36 to -72 VDC)
Fuses FOM-E1/T1:
• 115 VAC supply: 0.2A T 250V
• 230 VAC supply: 0.1A T 250V
FOM-E1/T1/R:
• 1A 250V and 50 mA 250V
Environment Temperature 0°–50°C / 32°–122°F
Humidity Up to 90%, non–condensing
