Installation and Wiring
1. Before Starting
Read these instructions and the following precautions
carefully.
WARNING!
Be sure to disconnect the battery (-)
terminal before starting. This is to
prevent short circuits during installation.
Precautions
• This unit is exclusively for cars with a negative ground, 12V
power supply.
• Do not open the case. There are no user-serviceable parts inside.
If you drop anything into the unit during installation, consult your
dealer or an authorized Rosen service center.
• Use a soft, dry cloth to clean the case. Never use a rough cloth,
thinner, benzene, alcohol, or other solvent. For tough dirt, apply a
small amount of cold or warm water to a soft cloth and gently
wipe.
2. Package Contents
• 410XR disc unit
• IR Remote control
• 4-pin Power Supply harness
• RCA Audio Cable
• Additional IR Receiver (with cable)
• Installation Brackets and Assorted Hardware
• Owner’s Manual / Installation Guide
• Warranty Card
3. Installation Requirements
1 Install the unit within 30 degrees of the horizontal plane.
Max. 30˚
2 Use the enclosed screws for installation. Using other
screws can cause damage and void the warranty.
Chassis Chassis
Damage
Max. 8 mm (M5 screw)
