4. Setting Up
This chapter describes how to set up the M38517T-ADS.
CAUTION
Note on Setting Up:
• Always shut OFF power before connecting this product. The power ON state could
destroy internal circuits.
4.1 Mounting an Emulator MCU
Mount an emulator MCU on the M38517T-ADS. After checking the position of the No. 1 pin of the
emulator MCU, mount the emulator MCU referencing Figure 4.1.
Figure 4.1 Position of No. 1 pin of an M38517T-ADS's emulator MCU
