6/32

FV-L200B1
User’s Guide Rev. 1.01

2.1.2

Vertical Timing

2.1.2.1

Normal Full Scanning

(Setting 10H: 1XX00XXX, 11H: X000X000)

1 H = 208.5963 μs, 3.8291 Hz at 3.8fps
1 H = 104.2968 μs, 7.6582 Hz at 7.6fps

1 H = 52.1484 μs, 15.3164 Hz at 15.3fps















2.1.2.2

Partial Full Scanning

(Settting 10H: 1XX01XXX, 11H: X000X000)

1 H = 208.5963 μs, 3.8599 Hz at 3.8fps
1 H = 104.2968 μs, 7.7199 Hz at 7.6fps

1 H = 52.1484 μs, 15.4397 Hz at 15.3fps

※ By transferring the blanking period pixels at a high rate, the frame rate of the partial full scanning can

be increased compared to that of the normal full scanning.

16H

1236H

Video out

FVAL

Vertical blanking

1252H

One vertical (1V)

1236H

16H

16H

Video output

1

2

1

2

3

5

1

2

3

6

16H

LVAL

DVAL

Vertical

blanking

Video out

FVAL

1242H

One vertical (1V)

1236H

6H

1236H

6H

Video output

1

2

1

2

3

5

1

2

3

6

6H

6H

LVAL

DVAL
