FV-L200B1
User’s Guide Rev. 1.01
Command
No.
R/W
Save to
EEPROM
Function
Initial Data
Data Range
78H
R/W
X
Test pattern selection (8bit: D[7..0])
0
0 to 31
79H
R/W
X
Image effect selection (8bit: D[7..0])
0
0 to 255
7A to 7FH
Reserved
80H
R/W
EEPROM control (8bit: D[7
0])
0
0 to 1
81 to 8FH
Reserved
-
-
94H
R/W
X
Strobe active period (us) (24bit: D[7..0])
95H
R/W
X
Strobe active period (us) (24bit: D[15..8])
96H
R/W
X
Strobe active period (us) (24bit: D[23..16])
0
0 to
2000000
97 to 9FH
Reserved
-
-
A0H
W
X
Pixel defect correction mode (8bit: D[7..0])
0
0 to 7
A1H
W
X
Pixel defect correction index (8bit: D[7..0])
0
0 to 15
A2H
W
X
PDC X coordinate (Write) (16bit: D[7..0])
A3H
W
X
PDC X coordinate (Write) (16bit: D[15..8])
0
0 to 65535
A4H
W
X
PDC Y coordinate (Write) (16bit: D[7..0])
A5H
W
X
PDC Y coordinate (Write) (16bit: D[15..8])
0
0 to 65535
A6H
R
X
PDC X coordinate (Read) (16bit: D[7..0])
A7H
R
X
PDC X coordinate (Read) (16bit: D[15..8])
0
-
A8H
R
X
PDC Y coordinate (Read) (16bit: D[7..0])
A9H
R
X
PDC Y coordinate (Read) (16bit: D[15..8])
0
-
AA –BFH
Reserved
-
-
C0H
R/W
X
Auto exposure min (16bit: D[7..0])
C1H
R/W
X
Auto exposure min (16bit: D[15..8])
1
0 to 4095
C2H
R/W
X
Auto exposure max (16bit: D[7..0])
C3H
R/W
X
Auto exposure max (16bit: D[15..8])
4095 (FFFH)
0 to 4095
C4H
Reserved
-
-
C5H
R/W
X
Look-up table (Gamma) (8bit: D[7..0])
0
0 to 6
C6H
R/W
X
ALC Speed (8bit: D[7..0])
0
0 to 255
C7 to EFH
Reserved
-
-
F0H
R/W
IO connector signals1 (8bit: D[7
0])
0
0 to 15
F1 to FFH
Reserved
-
-
