FV-L200B1
User’s Guide Rev. 1.01
2.2.2.3 Binning 1/2 Partial Scanning (setting 10H: 1XX11XXX, 11H: X000X001)
1 H = 208.5963 μs, 14.0588 Hz at 3.8fps
1 H = 104.2968 μs, 28.1175 Hz at 7.6fps
1 H = 52.1484 μs, 56.2350 Hz at 15.3fps
2.2.2.4 Binning 1/4 Partial Scanning (setting 10H: 1XX11XXX, 11H: X000X010)
1 H = 208.5963 μs, 24.3352 Hz at 3.8fps
1 H = 104.2968 μs, 48.6704 Hz at 7.6fps
1 H = 52.1484 μs, 97.3408 Hz at 15.3fps
285H
Video out
Vertical blanking
341H
One vertical (1V)
56H 56H
Video output
9
0
0
+
9
0
1
9
0
2
+
9
0
3
3
3
4
+
3
3
5
3
3
6
+
3
3
7
FVAL
285H 56H 56H
LVAL
DVAL
116H
Video out
Vertical blanking
197H
One vertical (1V)
116H
81H 81H
Video output
7
3
1
+
7
3
2
7
3
3
+
7
3
4
5
0
3
+
5
0
4
5
0
5
+
5
0
6
FVAL
81H 81H
LVAL
DVAL
