FV-L200B1
User’s Guide Rev. 1.01
Command No. Command Descriptions
A0H:
PDC0[7 0]
[Pixel defect correction mode] Initial data: PDC0[7..0] = 0
D[7..0]
D7 D6 D5 D4 D3 D2 D1 D0
D7: Write the correction index 0 1
*Writes the coordinates of the command, A2 to A5, to the index number specified by the
command A1.
*This bit is cleared to “0” automatically after the execution of the command.
D6 Read the correction index 0 1
*Reads the coordinates of the index number specified by A1 and loads them to the command,
A6 to A9.
*This bit is cleared to “0” automatically after the execution of the command.
D5: Save to the EEPROM 0 1
*Writes the coordinates of all 16 index numbers to the EEPROM.
*This bit is cleared to “0” automatically after the execution of the command.
D4 to D2 No function Always set as “000”
D1 Correction indices display 0: OFF 1: ON
D0 Pixel defect correction 0: OFF 1: ON
A1H:
PDC0[7 0]
[Pixel defect correction index number]Initial data: PDC1[7..0] = 0, data range: 0 to 15
D[7..0]
D7 D6 D5 D4 D3 D2 D1 D0
D7 to D4: No function Always set as “0000”
D3 to D0: Index number
A2H:
PDC_WX[7 0]
A3H
PDC_WX[15 8]
[PDC X coordinate (Write)]
Initial data: PDC_WX[15..0] =0, data range: 0 to the number of horizontal pixels of the effective area
Set the X coordinate of pixel defect.
A4H:
PDC_WY[7 0]
A5H
PDC_WY[15 8]
[PDC Y coordinate (Write)]
Initial data: PDC_WY[15..0] = 0, data rage: 0 to the number of vertical pixels of the effective area
Sets the Y coordinate of pixel defect.
A6H:
PDC_RX[7 0]
A7H
PDC_RX[15 8]
[PDC X coordinate (Read)]
Initial data: PDC_RX[15..0] = 0, data rage: 0 to the number of vertical pixels of the effective area
The X coordinate of pixel defect will be loaded when reading.
A8H:
PDC_RY[7 0]
A9H
PDC_RY[15 8]
[PDC Y coordinate (Read)]
Initial data: PDC_RY[15..0] = 0, data rage: 0 to the number of vertical pixels of the effective area
The Y coordinate of pixel defect will be loaded when reading.
C0H: [7 0]
C1H: [7 0]
[Lower limit of the electronic shutter] Initial data: 1; data range: 0 to 4,095
Sets the upper limit of the electronic shutter in horizontal lines when using AE (auto exposure).
C2H: [7 0]
C3H: [7 0]
[Upper limit of the electronic shutter] Initial data: 4,095; data range: 0 to 4,095
Sets the upper limit of the electronic shutter in horizontal lines when using AE (auto exposure).
