28
ST60 Tridata Instrument Owner’s Manual
•
Lock the shallow alarm.
•
Set the required units for speed readings.
•
Set the speed resolution.
•
Select the log distance units
•
Either calibrate the speed reading to Speed Over Ground (SOG) or
manually apply a calibration factor, to obtain correct speed through
the water.
•
Select temperature units.
•
Calibrate for correct temperature readings.
•
Set timer alarm buzzer on or off.
Separate routines are provided for the User calibration of the depth and
speed functions. To carry out either of these routines:
1. Power up the ST60 Tridata instrument.
2. Press the
depth
and
speed
keys for approximately 2 seconds so that
the User calibration entry screen is displayed.
3. Carry out the User calibration procedures for Depth and Speed.
To start User calibration
hold down
and
for approximately 2 seconds
speed
depth
speed
press either
depth
or
Starting User calibration
D4416-1
see illustration
User calibration - depth
see illustration
User calibration - speed
User calibration
entry screen
