Repair parts – RIDGID WD1850 User Manual

Page 16

background image

Key
No.

Part No.

Description

1

830564

Actuator, Switch

2

813213

Switch, Toggle

3

830701

Motor Cover Assembly

(Includes Keys 13 through 16)

4

830473

Filter Performance Sensor

5

830566-1

Motor Exhaust

6

828986

Motor Assembly

7

829718-8

Cord Assembly

8

819260-7

Lead Assembly

9

509836-1

Lid Assembly

(Includes Key 12)

10

VT2525

Muffler/Diffuser

11

820563-5

Screw, Pan Head Type “AB” #10 x 1-1/4

12

826387

Drum Latch

13

818961

Spacer

14

818413

Blower Wheel

15

315534-1

Washer

16

826817

Nut, Hex Flange 5/16-18

17

829692-2

Collector Assembly

18

820563-1

Screw, Pan Head Serrated Type “AB” #10 x 5/8

19

830578-1

Tube Cover

20

820563-11

Screw, Pan Head Recessed Type “AB” #10 x 1

21

830498-2

Tube

22

823200A

Float

23

823201-1

Filter Cage

24

VF5000

Filter - 2-Stage

25

73316

Filter Nut

26

VT2509

Utility Nozzle

27

VT2503

Car Nozzle

28

VT2510

Wet Nozzle

(Includes Key 30)

29

VT2502

Crevice Tool

30

822256

Squeegee

31

826356-5

Hose Assembly

32

VT2508

Extension, Handle

33

SP6528

Owner’s Manual

Repair Parts

16 Gallon Professional Wet/Dry Vac

Model Number WD18500

RIDGID parts are available on-line at www.ridgidparts.com

Always order by Part Number - Not by Key Number

† These replacement parts may be available where you purchased your vac.

16
