Chapter 9. Headers
9.1. Microcontroller Headers
Table 9-1 to Error! Reference source not found. show the microcontroller pin headers and their corresponding microcontroller
connections. The header pins connect directly to the microcontroller pin unless otherwise stated.
J1
Pin Circuit Net Name Device
Pin
Pin Circuit Net Name Device
Pin
1 CS1n_IO1 1 2 IO_2 2
3 CS3n_IO3 3 4 GROUND 4
5 IO_7 5 6 UC_VCC 6
7 MD2 7 8 PIN8 8
9 PIN9 9 10 LED0 10
11 SCK5 11 12 RXD5_A22 12
13 TXD5_A21 13 14 A20 14
15 A19 15 16 GROUND 16
17 A18 17 18 A17 18
19 A16 19 20 A15 20
21 A14 21 22 A13 22
23 GROUND 23 24 A12 24
25 UC_VCC 25 26 A11 26
27 A10 27 28 A9 28
29 A8 29 30 A7 30
31 A6 31 32 GROUND 32
33 A5 33 34 A4 34
35 A3 35 36 A2 36
Table 9-1: J1
