Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R116 Application
board interface
Use CS3n of application board
interface.
Use IO_3 of application board
interface.
R115
R123 Application
board interface
Use DA0 of application board
interface.
Use AN6 of application board
interface.
R54
R135 Application
board interface
Use TDO of application board
interface.
Use WDT_OVFn of application
board interface.
R157
R136 Application
board interface
Use DA1 of application board
interface.
Use AN7 of application board
interface.
R150
R137 Application
board interface
Use CS0n of application board
interface.
Use IO_0 of application board
interface.
R151
R142 Application
board interface
Use Un of application board
interface.
Use TIOCB0 of application board
interface.
R156
R143 Application
board interface
Use Up of application board
interface.
Use TIOCA0 of application board
interface.
R158
R150 Application
board interface
Use AN7 of application board
interface.
Use DA1 of application board
interface.
R136
R151 Application
board interface
Use IO_0 of application board
interface.
Use CS0n of application board
interface.
R137
R156 Application
board interface
Use TIOCB0 of application board
interface.
Use Un of application board
interface
R142
R157 Application
board interface
Use WDT_OVFn of application
board interface.
Use TDO of application board
interface.
R135
R158 Application
board interface
Use TIOCA0 of application board
interface.
Use Up of application board
interface.
R143
Table 6-6: Application board interface links.
Table 6-7 below describes the function of the option links associated with E8 and E10A debuggers. The default configuration is indicated
by BOLD text.
Option Link Settings
Reference Function Fitted Alternative (Removed) Related To
R4 E8 Enables E8
R118 E8 Programming Flash not using
SERIAL port.
Programming Flash using SERIAL
port.
R131 E8 If fitted or J7 is set board uses User
Boot Mode.
Removed or J7 isn’t set board
doesn’t use User Boot Mode.
R132 E10A Enables E10A, also can be enabled
by fitting J5.
E10A is disabled, can be
enabled if J5 is set.
Table 6-7: E8 and E10A debugger links.
