Installation
CX-70DHD Installation/Operation Manual 21
PRE
L
IMINAR
Y
If you choose to wall-mount the CX-70DHD, ensure that the wall-mount bracket is
installed according to the instructions included with it. The wall must be capable of
supporting a redundant weight factor five (5) times the weight of the display, or be
reinforced.
Runco recommends that this be done by a custom installation specialist.
3.4
Connections to the
CX-70DHD and DHD
Controller Proceed as follows to connect the CX-70DHD to the DHD Controller, your video sources,
external controller(s) – if present – and AC power.
When connecting your equipment:
• Turn off all equipment before making any connections.
• Use the correct signal cables for each source.
• Ensure that the cables are securely connected. Tighten the thumbscrews on
connectors that have them.
Connecting the
CX-70DHD to the DHD
Controller Connect the DHD Controller to the CX-70DHD as shown in Figure 3-4 and described in
the sections that follow.
Use only a Runco-approved wall-mount kit or table stand that is
specifically designed for your display. Refer to Parts List on page 4
for ordering information.
Note
