7.1
PlasmaWall
Specifications
Table 7-1 lists the PlasmaWall specifications.
7. Specifications
Table 7-1. PlasmaWall Specifications
Native Resolution:
PL-43DHD: 1024 x 768
PL-50DHD: 1280 x 768
Screen Size (diagonal):
PL-43DHD: 43 inches
PL-50DHD: 50 inches
Active Screen Area:
PL-43DHD: 37.375 x 21.125 in. (949.3 x 536.6 mm)
PL-50DHD: 43.250 x 24.500 in. (1098.5 x 622.3 mm)
Screen Aspect Ratio:
16:9
Available Aspect Ratios:
Refer to Table 7-2
DTV Compatibility:
480p, 720p, 1080i
Contrast Ratio:
1000:1
ISF Settings:
Yes
Data/Graphics Compatibility:
Up to 1600 x 1200
Inputs:
(1) DVI 1.0 with HDCP
(1) RGB/Component (15-pin D-sub)
(1) RS-232 (9-pin, D-sub male)
(1) Combination in/out (6-pin mini-DIN jack)
Power Requirements:
100 to 120 VAC, 50/60Hz
220 VAC (pre-set at the factory only)
Power Consumption (typical):
PL-43DHD: 380 W
PL-50DHD: 480 W
Operating Environment:
32ºF to 104ºF (0ºC to 40ºC);
20% to 80% humidity (non-condensing)
Dimensions:
PL-43DHD: See Figure 7-1
PL-50DHD: See Figure 7-2
Weight:
PL-43DHD: 80.0 lbs. (36.29 kg)
PL-50DHD: 96.0 lbs. (43.55 kg)
Regulatory Approvals:
Complies with FCC
Limited Warranty:
Three (3) years parts and labor from the date of delivery to
the end user (except for plasma glass panel).
Plasma Glass Panel: One (1) year parts and labor from the
date of delivery to the end user.
Specifications are subject to change without notice.
