Installation
24 Runco PL-43DHD and PL-50DHD Owner’s Operating Manual
PRE
L
IMINAR
Y
Digital (DTV) RGB Connections: See Figure 3-6.
Figure 3-6. Digital (DTV) RGB Connections
DVI 1
HD1
HD2
G/Y
INPUTS
H V R/Pr B/Pb
G/Y H V R/Pr B/Pb
DVI 2
Component Video
Pb Pr Y Video S-Video 2
S-Video 1
1 2 3
TRIGGERS
DTV or Progressive
Component (YPbPr)
Source
Red/Pr Green/Y Blue/Pb Horiz Vert
