Ricoh Aficio 615C User Manual
Page 26
Getting Started
12
1
B
Tilt the control panel upwards, and then release the adjustment button to
lock the panel.
C
To tilt the control panel downwards, press the adjustment button to unlock
the panel, and then gently adjust it until it locks into position.
Be careful not to get your fingers caught in the gap between the control panel
and the machine.
A
gap
Note
❒ You can adjust the tilt of the control panel to either 7°, 30° or 53°.
ALZ063S
ALZ066S
ALZ064S
