Page 25
Guide to Components
11
1
1.
Main power switch
If the machine is not powered on after
pressing the Operation switch, check that
the main power switch is turned on. If it
is off, turn it on.
Control Panel Angle Adjustment Button
By pressing the control panel angle adjustment button, you can adjust the tilt of
the control panel.
Important
❒ Do not force the control panel or adjust it without pressing the adjustment
button. Doing so damages the control panel.
A
Press the control panel adjustment button on the right side of the machine.
ALZ015S
ALZ065S
