56
Runco VX-44d/-55d Owner’s Operating Manual
PRE
L
IMINAR
Y
6.
It may be advantageous to go back and check the black band. Adjust the blacklevel
slidebar if necessary.
7.
Repeat Steps 4 through 6 with the other two remaining primary colors. When each
primary color shows one optimized black band and white (or colored) band, the input
levels for this source are correctly set. Upon exiting the White Balance menu, the
Clipping Detector checkbox will clear.
• Color Enable: Select which color or colors you want to see in the display. This is
useful when working with color temperature white levels or black levels.
When you have finished optimizing the picture quality, lock the channel that you unlocked
previously (refer to Unlocking Channels on page 48), unlock the next channel and
repeat the calibration procedure. Do this for each of the remaining channels.
Installation Menu
Select Installation from the VX-44d/-55d Main Menu to access these advanced lamp
and lens configuration options:
• LumaCal™, for maintaining constant lamp brightness
• OptiCal™, to save and restore lens positions
Calibration and Test Patterns – LumaCal (Lamp Calibration): LumaCal defines the
range of power needed to maintain lamp brightness over time.
To use LumaCal:
1.
Select Installation from the Main Menu.
2.
Select Calibration and Test Patterns from the Installation Menu.
3.
Select LumaCal from the Calibration and Test Patterns Menu.
4.
Select Calibrate LumaCal to calibrate the lamp using your projector's unique
specifications (recommended). Or, select Use Default Settings to undo the effects
of a previous calibration.
In the event of a power failure, the projector reverts to the default LumaCal settings in
which case you should re-calibrate the lamp.
Readjusting the black levels affects the gain at this point; only
readjust when absolutely necessary.
Note
➤
1. Language
English
2. Picture
Orientation
Front
3. Reserved
4.
Auto Power On
5. Set
Date
and
Time
6. OSD
Adjust
7.
IR and Serial Adjust
8. Geometry
and
Color
9.
Calibration and Test Patterns
0. Service
Mode
Option 1 Card: Empty
Option 2 Card: Empty
Installation
1. Test
Patterns
Grid
2.
Test Pattern Level
512
3. Freeze
4. Color
Enable
White
5. Odd
Pixel Adjustment
6. Reserved
7. Clipping
Detector
8. Level
Detector
9. Level
Value
512
0.
LumaCal Calibrate
LumaCal
OptiCal Full
Aspect
Ratio
Overlay
Calibration and Test Patterns
For best results, allow the projector to warm up for 15 minutes prior
to using LumaCal.
LumaCal lamp calibration takes approximately two minutes.
Note
Note
