Runco VX-44d/-55d Owner’s Operating Manual
23
PRE
L
IMINAR
Y
Table 3-4 lists the lens shift limits for each available VX-44d/-55d lens, as percentages
and absolute measurements with a 100 x 56 inch (1.78:1) screen.
Table 3-4. Vertical and Horizontal Lens Shift Limits
Lens Option
Telesto B, Telesto C or
Telesto E
Telesto D
Lens Shift Limits, as Percentages of Screen Height or Width (Notes 1, 2 and 3)
Vertical
(Notes 2 and 3)
Up
60%
60%
Down
60%
60%
Horizontal
(Note 2)
Left
22%
20%
Right
22%
20%
Lens Shift Limits in Inches, with a 100-by-56 inch (1.78:1) Screen
Vertical
Up
33.60
33.60
Down
33.60
33.60
Horizontal
Left
22.00
20.00
Right
22.00
20.00
Notes:
1. With no vertical or horizontal lens shift, the lens center and screen center are aligned with each
other.
2. Vertical shift limits are percentages of the screen height. Horizontal shift limits are percentages of
the screen width.
3. Vertical lens shift figures are for ceiling mount configurations. For floor installations
(where the projector is upright), reverse the up/down vertical lens shift percentages.
