Figure 3-4 . horizontal lens shift, 4. horizontal lens shift, Figure 3-4 – Runco 1080p User Manual
Page 34: Pre l iminar y
22
Runco VX-44d/-55d Owner’s Operating Manual
PRE
L
IMINAR
Y
Figure 3-4. Horizontal Lens Shift
0%
Screen Center
100% Width Lens Shift
(1.0 x W)
50% Width Lens Shift
(0.5 x W)
150% Width Lens Shift
(1.5 x W)
Screen Width (W)
Note: This is a general example of lens shift. Lenses vary in their shift capabilities.
No particular
lens or projector is used in this example.
