Continuation TROUBLE SHOOTING GUIDE

3d. Excessive negative pressure exerted

by the exhaust system on the vent will
prevent N.O. combustion air/vent
switch from closing. Provide means to
relieve pressure and close the N.O.
switch. If combustion air/vent switch
will not close, replace switch.

3e. Disconnect igniter leads from ignition

module. Make sure 24V is present
across ignition terminals on the igni-
tion module during the ignition cycle.
If not, replace ignition module. Check
resistance reading across igniter
leads. If circuit is open, or reading is
greater than 30 ohms, replace the
igniter. A new igniter will measure
between 1 to 6 ohms at room tem-
perature.

3f. During the ignition cycle, 24V should

be present at the MV1 and GND termi-
nals for about 5 seconds. If no 24V is
measured, replace the ignition mod-
ule. If 24V is present, replace the gas
valve.

4a. Check ground connections inside

control box.

4b. Check all connections and wire nuts.
4c. Check wire connection to remote sen-

sor.

4d. Check gas pressure at outlet of valve

under load, pressure should be:

3.5 in. W.C.for Natural gas
10.5 in. W. C. for Propane gas.

5a. Ensure supply water temperature is at

least 140°F.

5b. Ensure dishwasher operates correctly.

Check rinse cycle time and inspect
spray nozzles for correct pressure
setting or damage.

5c. Adjust operating limit to minimum tem-

perature that provides 180°F rinse.
(Do not set above 185°F).

-Verify booster operates correctly, if

not, recheck all procedures listed
above.

3d. Excessive vent exhaust or

defective air/vent switch.

3e. Ignition module or igniter

may be defective.

3f. Gas valve or the ignition

module may be defective.

4a. Improper ground

4b. Loose wiring.
4c. Remote sensor

4d. Insufficient gas pressure.

5a. Supply water temperature

too low.

5b. Dishwasher times not set

properly.

5c. Operating limit set too low.

4. Unit energized, pump and

blower running.

Ignitor is glowing.
Burners will not stay lighted.

5

Unit does not produce

suffcient hot water
