Page 20

2-2
Raynav 300 GPS Plotter
Figure 2-1: GPS Status Screen
The GPS Status screen is displayed until a satellite fix has been acquired.
When satellite acquisition is complete, the READY FOR NAVIGATION
pop-up box displays for two seconds.
To proceed whilst satellite acquisition continues, press the CLEAR key;
the GPS Data Screen is displayed.
Figure 2-2: GPS Data Screen
➤
To switch the display unit off, press and hold the POWER key for at least
three seconds. A 3-second countdown timer is displayed; when it reaches
D-GPS
SET UP
GPS STATUS
HDOP
FIX STATUS
SAT SIGNAL STATUS
15
09
08
10
20
17
LOCKED
IN USE
IN USE
LOCKED
LOCKED
LOCKED
1.0
D-FIX
SAT SIGNAL STATUS
23
18
26
12
14
03
LOCKED
IN USE
IN USE
LOCKED
LOCKED
LOCKED
D5551_1
RESTART
GPS
FIX MODE
GPS D
SD
WPT BRG
WPT RNG
COG
SOG
320°M
50°50^000N
001°06^000W
0.55nm
12.0kts
050°M
SD-FIX
STEER STARBOARD
WPT 004
D4936-1
GOTO
GPS DATA
ROUTE
WPT DATA
