SH7211 Group
Data Transfer between On-chip RAM Areas with DMAC (Cycle-Stealing Mode)
REJ06B0732-0100/Rev.1.00 March 2008 Page 2 of 13
1. Introduction
1.1 Specification
• DMAC channel 0 is used.
• Auto-request mode is used as the interrupt source for activating DMA transfer.
• Cycle-stealing mode is used as the bus mode.
1.2 Used Module
• Direct memory access controller (DMAC channel 0)
1.3 Applicable Conditions
• Microcontroller: SH7211
• Operating Frequency:
Internal clock 160 MHz
Bus clock 40 MHz
Peripheral clock 40 MHz
• C Compiler:
SuperH RISC engine family C/C++ compiler package Ver.9.01,
from Renesas Technology
