User Guide 13
How do I follow a zig-zag pattern?
3
1 2
Quick Tip
ZIGZAG
From any screen:
1. Press MODE repeatedly until
ZIGZAG is displayed.
2. Use the PORT and
STARBOARD keys to change
the size (S, M or L) if required
3. Press the PILOT key to activate
the autopilot
change pattern size
(Sml, Med or Large)
press repeatedly until
you reach ZIGZAG
activates autopilot
in ZIG ZAG mode
MODE
PILOT
When you enter ZIGZAG mode, the autopilot will use your current
position and heading as the center line of the zig-zag. The autopilot
will now gently steer your boat into the pattern starting with a turn to
starboard.
Fishing patterns are designed to work at speeds
up to 15kts. Check your speed before starting.
D7621-1
