Rover Mowers Limited Ride-on Mower Grass Catcher
The Rover Ride-on Mower Grass Catcher has been designed to be fitted to and used with the Rover Rancher, Raider
and Lawn King, fitted with either the 30" or the 38" pressed steel cutterheads.
The correct model grass catcher to suit the Rover Rancher, Raider and Lawn King models and cutterhead combination
can be selected from the "Grass Catcher Selection Chart" (See Section 1. 1 below).
Some Rover Ride-on Mowers will need to have a towbar fitted and/or the use of a different mount support bracket before
the Rover Grass Catcher can be correctly mounted. These mowers are identified in the chart below by an asterisk *
1.
SETTING UP
1.1 Grass Catcher Selection
Cutterhead
Catcher
Towbar
Mount support
Rover Ride-on Mower
Model No.
Model No.
Model No.
Model 110
Bracket
Required
A12 942
Rancher Selector Drive
17166
180
108
*
198
109
Rancher Selector Drive
27166
180
108
*
198
109
*
Rancher Selector Drive
17188
180
108
*
198
109
Rancher Selector Drive
27189
180
1'08
*
198
109
*
Rancher Auto-Drive
18166
180
108
*
198
109
Rancher Auto-Drive
28166
180
108
*
198
109
*
Rancher Auto-Drive
18188
180
108
*
198
109
Rancher Auto-Drive
28189
180
108
*
198
109
*
Rancher H dro
28266
180
108
*
Raider
4078
180
108
Lawn King Hydro
2950
180
108
198
109
WARNING
The Rover Grass Catcher Models 108 and 109 are designed for
front engine ride-on mowers ONLY!
DO NOT FIT lO8/l09 Grass Catchers to rear engine mowers.
Before proceeding with the assembly
of
the grass catcher, remove the loose parts kit from the carton.
1.2 Loose parts kit – Model 108 (30” Cutterhead)
1.3 loose parts kit – Model 109 (38” Cutterhead)
Item
No. Su lied
Transfer tube
1
Chute assembly
1
Rod-outlet chute
1
Fan disks assembly
1
Grass catcher assembly
1
Support bracket
1
Owner's manual
1
Side frame
2
Spreader
1
Bolt - 3/8 x 1" unc.
2
Nycloc nut - 3/8" unc.
3
Nyloc nut –
¼
" unc.
4
Screw -
3
/16' x 1" unc. RH.
4
Nyloc nut -
3
/16' unc.
4
Washer - 3/8" flat
2
Item
No. Su lied
Transfer tube
1
Chute assembly
1
Rod-outlet chute
1
Grass catcher assembly
1
Support bracket
1
Owner's manual
1
Side frame
2
Spreader
1
Bolt - 3/8 x 1" unc.
2
Nyloc nut - 3/8" unc.
3
Nyloc nut –
1
/4" unc.
4
Screw -
3
/16' x 1" unc. RH.
4
Nyloc nut -
3
/16' unc.
4
Skirt
1
Bolt-
5
/16' x ¾" cuphead
2
Washer -
5
/16' flat
2
Nyloc nut -
s
/16" unc.
2
Washer - 3/8" flat
4
