10
Efficiency 80% (minimum) at full load
80% at typical load
80% at light load
Standby <1 W when +5 VSB <0.1 A @115 V/60 Hz
Output ripple and noise +3.3 V 50 mV p-p
+5 V 50 mV p-p
+12 V 1 and 2 120 mV p-p
-12 V 120 mV p-p
+5 VSB 50 mV p-p
Output protection Yes
Over voltage protection Yes
Short circuit protection Yes
Over current protection Yes
Hi-Pot (the power supply is
capable of withstanding) Input to ground voltage: 1800 VAC
Test time: 3.0 S
Cutoff current (maximum): 10 mA
Leakage current 3.5 mA maximum (at 230 Vrms, 50 Hz)
Grounding resistance 100 mOhm maximum at 25 A
Environmental
Operating temperature
32°F to 104°F (0°C to 40°C)
Storage temperature -40°F to 131°F (-40°C to 55°C)
Operating humidity
(non-condensing) 5% to 95% RH
Vibration (non-operating) Swing: 0.35 mm
Frequency: 10-55-10 Hz
Degree: 5 times per axis, 30 minutes, log sweep p-p
Acceleration: 19.98 m/s
2 @ a frequency of 55 Hz
Safety compliance IEC60950-1, EN60950-1, UL60950-1, and GB4943
Safety approval UL, C-UL, and FCC
