6

Cable connections

8-pin (4+4) 20+4 pin

8-pin to 8-pin
(6+2) PCI Express
(2 cables)

6-pin to HDD (3)
+floppy (1)

6-pin to SATA (3)
(2 cables)

6-pin to HDD (4)
