Table 1 lists the HS2214ECB61H components. Please make sure you have all of these components
when unpacking.

Table 1

HS2214ECB61H Components

No. Component

Quantity

Remarks

1

Cable body

1

Includes flat cable

2 Cable

head

1

3

IC socket

1

For the TBP-112 package

4

Spacer

1

For installing an TBP-112 packaged MCU

5

Cover

1

For installing an TBP-112 packaged MCU

6

Screws (M1.6 x 8 mm)

4

For fastening cable head and for installing an
TBP-112 packaged MCU

7 Driver

1

Dedicated

screwdriver to fasten the screws.

8 Documentation

1

User’s

manual for HS2214ECB61H (this manual)
