33
Table N: Temperature Control Default Setpoints
Item Modes Default Setting Range
Boil Target
1, 2 160°F OFF, 70 to 220°F
3 160°F OFF, 70 to 190°F
4, 5, 6, 7 180°F OFF, 70 to 220°F
Boil Max
1, 2, 4, 5, 6, 7, 8 200°F OFF, 120 to 225°F
3 180°F OFF, 120 to 190°F
Boil Min 1, 2, 3, 4, 5, 6, 7 150°F OFF, 80 to 180°F
‘Burner’ Delay All 0:00 min 0:00 to 3:00 min
Boil Mass All 1 (Low) 1 (Low), 2 (Med), 3 (High)
Diff 1, 2, 3, 4, 5, 6, 7 Auto Auto, 2 to 42°F
DHW Target 3 120°F OFF, 70 to 190°F
DHW Diff 3 5°F 2 to 10°F
‘Pump’ Dly All 3:00 min OFF, 0:20 to 9:55 min, ON
Outdr Start 4, 5 70°F 35 to 85°F
Outdr Design 4, 5 -10°F -60 to 32°F
Boil Start 4, 5 135°F 35 to 150°F
Boil Dsgn 4, 5 180°F 120 to 220°F
WWSD 4, 5 70°F 35 to 100°F
Units All °F °F or °C
Mode N/A 2 1, 2, 3, 4, 5, 6, 7, 8
External Input Signal 6, 7 2 to 10 VDC 2 to 10 VDC or 0 to 10 VDC
Offset 6, 7 0°F -10°F to 10°F
