2
Table 1 lists the HS1527ECH61H components. Please make sure you have all of these components
when unpacking.
Table 1 HS1527ECH61H Components
No. Component Quantity Remarks
1 Cable body 1 Cable
2 Cable head 1
3 IC socket 1 For the FP-100M package
4 Socket cover 1 For installing an FP-100M packaged MCU
5 Screws (M2.6 x 12 mm) 4 For fastening cable head (with four flat washers)
6 Screws (M2.6 x 6 mm) 4 For installing an FP-100M packaged MCU (with
four flat washers)
7 Documentation 1 User’s manual for HS1527ECH61H (this manual)
