Renesas H8SX/1520 User Manual
Page 15
11
2.5
Resulting Dimensions after Connecting User System Interface Cable
The resulting dimensions, after connecting the user system interface cable head to the user system,
are shown in figure 7.
16.0
21.5
Cable head
User system
Unit: mm
Tolerance: ±0.5 mm
IC socket
(IC149-100-054-B51
manufactured by
YAMAICHI ELECTRONICS Co. Ltd.)
Figure 7 Resulting Dimensions after Connecting User System Interface Cable
