Next Generation GPS 32-Channel Bluetooth GPS BT-Q880 Operating Manual
QSTARZ Technology Inc. 6F-2, No. 160, Ming Chuan E. Road, Sec. 6, Taipei,Taiwan
Tel: ++886 2 2792 0061 Fax: ++886 2 2792 0062 E-Mail: [email protected] Web: www.Qstarz.com
7
C. Hardware interface
C.1 Physical
Size: 83.0(W) x 44.5(D) x 23.5(H) (mm)
3.27"(W) x 1.75"(D) x 0.93"(H).
Weight: 72g (battery included)
C.2 Hardware Interface
The BT-Q880 includes a new generation low power GPS module, a Bluetooth module and a Li-ION
rechargeable battery in a unique style gadget. Simply place it on the dashboard (with our patent pending
Easy-Place
) of the car or any place which is not deeply covered by metal or other heavy material for
transmitting GPS signal to your notebook PC, PDA or other devices, which facilitated with Bluetooth functions.
C.3 Connector
Battery recharging connector: 4.0mm DC jack, with center “+” (positive).
Active antenna connector: MMCX
C.4 Accessories
Standard:
80026: Easy-Place, 35mm round pad sticking on the dashboard or other place for hold BT-Q880
A-6003-E: Travel adapter, with 120V, 230V adapter
A-9004: Lithium-ION, rechargeable battery, 1000mAh
A-6024-40: Cigarette Adapter, DC Jack 4.0mm, 850mA, 5 meter
C.5 Switch Function
Switch Function
OFF Off System power Off
ON On For paring and operating of Bluetooth GPS.
AUTO Auto
1. Works on Auto ON-OFF function (Patent pending)
2. Automatically starts when Car Engine Starts (Through Cigarette Adapter).
3. Automatically switch off the power when Car Engine is off or un-plug the
Cigarette Adaptor.
C.6 GPS BT LED STATUS
Function
ON OFF AUTO
ON Position Fixed
/Connection
Not Applicable Positioned Fixed
/Connection
OFF
GPS not powered
Not Applicable
Not Applicable
FLASH Position not fix
/No connection
Not Applicable Position not fix
/No connection
LED
