Next Generation GPS 32-Channel Bluetooth GPS BT-Q880 Operating Manual
QSTARZ Technology Inc. 6F-2, No. 160, Ming Chuan E. Road, Sec. 6, Taipei,Taiwan
Tel: ++886 2 2792 0061 Fax: ++886 2 2792 0062 E-Mail: [email protected] Web: www.Qstarz.com
4
A.8.3 Manufacturing Setting
Datum: WGS84
Sentence: GGA, GLL, GSA, GSV, RMC, VTG
Baud Rate: Auto
A.8.4 GPS features
Next generation sensitivity at -157dBm (-187dBw)
32-channel acquisition parallel
A.8.5 BT Feature
Sensitivity: -85dBm
Bluetooth V1.2 SPP profile
A.8.6 Overall Feature
Low power consumption: <80mA
A. Introduction
A.1 Overview
The BT-Q880 Bluetooth GPS Receiver is a total solution GPS receiver with Bluetooth wireless transmitting
ability, designed based on
next generation indoors GPS technology with super sensitivity at -157dBm
(-187dBw) and low power (<80mA) consumption. This revolutionary system provides you unbelievable
positioning sensitivity allowing you to have easy and quick position fix in urban canyon conditions. You may use
this device for strict needs of positioning applications such as car navigation, mapping, surveying, security,
agriculture and so on.
The BT-Q880 communicates with other electronic utilities wireless Bluetooth technology. It acquires 32
satellites parallel when cold start, and display the best 8 signals for power saving purpose.
A.2 Features
The BT-Q880 provides a host of features that makes it easy for integration and use.
1. Patent
pending AUTO ON-OFF function makes you hands-free once you place the device in place.
2. Patent pending Easy-Place function makes the device placed without sliding around the car in a snap.
3. Wireless transmitting positioning status up to 10 meters.
4. High sensitivity receiver acquires 32 satellite signals parallel while providing first fast fix and low power
consumption.
5. Advanced design ideal for applications with soft touch and minimal space.
6. User initialization is not required.
7. Automatically baud rate setting, user does not need to do any selection.
8. FLASH based program memory: New software revisions upgradeable both for GPS and Bluetooth. (For
distributor only)
9. LED display status: The LED provides users visible operating status for Recharging, Battery power lever,
Bluetooth and GPS. No more extra device needed.
10. Rechargeable Li-ION battery provides you a durable use.
A.3 Technology specifications
A.3.1 Physical Dimension
Single construction integrated antenna/receiver.
Size: 83.0(W) x 44.5(D) x 23.5(H) (mm)
3.27"(W) x 1.75"(D) x 0.93"(H).
Weight: 72g (battery included)
A.3.2 Environmental Characteristics
1) Operating temperature: -30 o C to +85 o C.
2) Storage temperature: -50 o C to +100 o C.
A.3.3 Electrical Characteristics
1) Input Power:
