Mounting the Base Directly
on the Wall
For this mounting method, you need
two flat-head wood screws (not sup-
plied) with heads that fit into the key-
hole slots on the bottom of the base.
1. Drill two holes 3 5 /
16
inches apart. Then
thread a screw into
each hole, letting the
heads extend about
3 /
16
inch from the
wall.
2. Insert the two catches at the top of
the bracket into the upper slots on
the bottom of the base. Then
press the two latches on the sides
of the bracket into the lower slots.
3 /
16
3 5 /
16
3. Plug one end of the supplied long
modular cord into the TEL LINE
jack on the back of the base.
4. Route the modular cord through
the wide right groove on the bot-
tom of the bracket.
AC ADAPTOR
DC IN 9V
PULSE-TONE TEL LINE
