10
• If you have two phone lines and you want to connect
the AFX-300 to the second line, you must install a tri-
plex modular adapter, such as Radio Shack Cat. No.
279-469, and connect the AFX-300 to L2. Follow the
installation instructions provided with the adapter.
• You can mount the AFX-300 on a standard modular
wall plate or directly on a wall using two screws (not
supplied), then connect the AFX-300 to the telephone
line using a short modular cord (not supplied).
2. To connect a fax machine, fax modem, or fax/data
modem, plug its modular plug into the AFX-300’s FAX
jack.
OPEN
RESET
Mounting on a Wall Plate Mounting Directly on a Wall
