Renesas M30220T-PRB User Manual
Page 28
( 26 / 36 )
(3) External Dimensions of Converter Board (FLX-144NSE)
Figure 4.3 shows the external dimensions and a sample foot pattern of the pitch converter board FLX-
144NSE for 144-pin 0.4mm-pitch TQFP.
Figure 4.3 External dimensions of FLX-144NSE
(4) External Dimensions of Converter Board (FLX-120NSE)
Figure 4.4 shows the external dimensions and a sample foot pattern of the pitch converter board FLX-
120NSE for 120-pin 0.4mm-pitch LQFP.
Unit: mm
Unit: mm
Figure 4.4 External dimensions of FLX-120NSE
