Chapter 4. Specifications
4.1 Specifications
Table 4.1 lists the specifications of the M30220T-PRB.
Table 4.1 Specifications of M30220T-PRB
PC4701M, PC4701HS or PC4701L
M30200T-RPD-E
M30220 and M30221 Group MCUs
Single-chip mode
1MB
X
IN
=10MHz
X
IN
=7MHz, 1 wait
+2.7 to 5.5V
Max. 8 bytes
16-byte dump: approx. 312 BCLK cycles
16-byte fill: approx. 283 BCLK cycles
1. Supplied from an emulator main unit
2. The operating voltage of the emulation pod main unit is
determined by detecting the supply voltage of the target
system. When no target system is connected, or when the
supply voltage of the target system is more than 5.0V, the
operating voltage is 5.0V.
5 to 35
°
C (no dew)
-10 to 60
°
C (no dew)
Emulators
Emulation pod main unit
Applicable MCUs
Usable MCU mode
Emulation memory
Operating frequency
Power supply range
Stack capacity used for emulator
Suspended cycles
in run-time debug
Operating temperature range
Storage temperature range
Power supply to emulation pod
main unit
4.0 to 5.5V
2.7 to 5.5V
M30220 Group
144-pin 0.5mm-pitch LQFP
(144P6Q-A)
144-pin 0.4mm-pitch TQFP
(144PFB-A)
120-pin 0.4mm-pitch LQFP
(120P6R-A)
M30221 Group
Connection to the target system
(See "3.4 Connecting to the Target
System", page 17)
FLX-144NSD
(included)
FLX-144NSE
(option)
FLX-120NSE
(option)
