11
3. Plug one end of the supplied long
modular cord into the TEL LINE jack
on the back of the base.
4. Insert the supplied AC adapter’s
barrel plug into the DC IN 9V jack.
5. Route the modular and adapter’s
cords through the grooves on the
bracket as shown.
6. Align the bracket’s keyhole slots
with the mounting screws and slide
the base downward to secure it.
7. Plug the modular cord’s other end
into a modular telephone line jack.
8. Plug the adapter into a standard AC
outlet.
9. Press and lift out the handset hold-
er, flip it over as shown, then snap it
back into place so it holds the hand-
set.
10. Lift the base’s antenna to a vertical
position.
Grooves
