Renesas SH7050 Series User Manual
Page 23
12
2.6
Resulting Dimensions after Connecting User System Interface Board
The resulting dimensions, after connecting the user system interface board to the user system, are
shown in figure 7.
IC socket
(Tokyo Eletech Corporation
CSPACK256Z2021H01)
User system
EV-chip board
Spacer (
φ
6.0)
65.0
45.0
45.0
65.0
28.4
8.7
53.7
Unit: mm
Tolerance: ±1.0 mm
Figure 7 Resulting Dimensions after Connecting User System Interface Board
