2 exchanging the spacer of the ev-chip board – Renesas SH7050 Series User Manual
Page 18
7
2.2
Exchanging the Spacer of the EV-Chip Board
While the user system interface board is connected to the user system, force must not applied to
the user system.
Exchange the spacer (2.6MP x 10 mm) of the EV-chip board with another spacer (2.6MP x 25
mm) provided for the user system interface board.
EV-chip board
Spacer
(2.6MP x 25 mm)
Figure 3 Exchanging the Spacer
