(4/4)
7. Precautions
CAUTION
Cautions to Be Taken for This Product:
z When connecting the YQPACK100SD, be sure to use the included YQ-GUIDEs.
z Do NOT use the screws included with the YQPACK100SD for connecting the YQPACK100SD.
IMPORTANT
Notes on This Product:
z We cannot accept any request for repair.
z For purchasing the NQPACK100SD-ND, YQPACK100SD and HQPACK100SD, contact the following:
Tokyo Eletech Corporation
http://www.tetc.co.jp/e_index.htm
z For inquiries about the product or the contents of this manual, contact your local distributor.
Renesas Tools Homepage
http://www.renesas.com/tools
8. Correspondence of Connectors CN1 and CN2
Table 2 Correspondence of the connectors
CN1 Pin No.
IC1
CN1 Pin No.
IC1
CN2 Pin No.
IC1
CN2 Pin No.
IC1
1
-
100
-
1
-
100
-
2
-
99
-
2
-
99
-
3
-
98
-
3
-
98
-
4
-
97
-
4
-
97
-
5
57
96
56
5
-
96
-
6
58
95
55
6
-
95
-
7
59
94
54
7
-
94
-
8
60
93
53
8
-
93
-
9
61
92
52
9
-
92
-
10
62
91
51
10
-
91
-
11
63
90
50
11
-
90
-
12
64
89
49
12
-
89
-
13
65
88
48
13
-
88
-
14
66
87
47
14
-
87
-
15
-
86
-
15
-
86
-
16
67
85
46
16
-
85
77
17
68
84
45
17
-
84
78
18
69
83
44
18
-
83
79
19
70
82
43
19
-
82
80
20
71
81
42
20
-
81
81
21
72
80
41
21
-
80
82
22
73
79
40
22
-
79
83
23
74
78
39
23
-
78
84
24
75
77
38
24
-
77
85
25
76
76
37
25
-
76
86
26
-
75
-
26
-
75
-
27
97
74
36
27
-
74
87
28
98
73
35
28
-
73
88
29
99
72
34
29
-
72
89
30
100
71
33
30
-
71
90
31
1
70
32
31
-
70
91
32
2
69
31
32
-
69
92
33
3
68
30
33
-
68
93
34
4
67
29
34
-
67
94
35
5
66
28
35
-
66
95
36
6
65
27
36
-
65
96
37
-
64
-
37
-
64
-
38
7
63
26
38
-
63
-
39
8
62
25
39
-
62
-
40
9
61
24
40
-
61
-
41
10
60
23
41
-
60
-
42
11
59
22
42
-
59
-
43
12
58
21
43
-
58
-
44
13
57
20
44
-
57
-
45
14
56
19
45
-
56
-
46
15
55
18
46
-
55
-
47
16
54
17
47
-
54
-
48
-
53
-
48
-
53
-
49
-
52
-
49
-
52
-
50
-
51
-
50
-
51
-
(-:No connection or signals in the emulator)
