2.1 Package Components
The M3062PT-EPB package consists of the following items. When unpacking it, check to see if your
M3062PT-EPB contains all of these items.
Table 2.1 Package components
* Please keep the M3062PT-EPB's packing box and cushion material in your place for reuse at a
later time when sending your product for repair or other purposes. Always use these packing box
and cushion material when transporting this product.
* If there is any question or doubt about the packaged product, contact your local distributor.
* For purchasing the IC61-1004-051 or for technical information, contact Yamaichi Electronics Co., Ltd.
http://www.yamaichi.co.jp/e/index.shtml
2.2 Other Tool Products Required for Development
To bring forward programs development on an M16C/62P MCU of the M16C/62 Group, the products
listed below are necessary in addition to those contained package above. Get them separately.
Table 2.2 Other tool products required for development
* For purchasing these products, contact your local distributor.
Item
M3062PT-EPB emulation probe
M30800T-PTC converter board for 100-pin 0.65-mm-pitch LCC
IC61-1004-051 LCC socket (100-pin 0.65-mm-pitch) made by Yamaichi Electronics Co., Ltd.
OSC-3 (16 MHz) oscillator circuit board
OSC-2 oscillator circuit bare board
Resistor arrays (51 k Ω ) for ports P0 to P5 pullup
Hardware tool user registration FAX sheet (English)
Hardware tool user registration FAX sheet (Japanese)
M3062PT-EPB user's manual (this manual)
M3062PT-EPB user's manual (Japanese)
Quantity
1
1
1
1
1
6
1
1
1
1
M3T-100LCC-DMS
+
M3T-DIRECT100S
M3T-100LCC-DMS
+
M3T-DUMMY100S
M3T-100LCC-DMS
+
M3T-FLX-100NRB
M3T-F160-100NSD
M3T-100LCC-QSD
M3T-100LCC-DMS
+
M3T-FLX-100NSD
Product
Emulator main unit
Emulator debugger
Product name
PC7501
M3T-PD30F
Converter boards
Notes
Required
Required
128-pin 0.5-mm-pitch LQFP
(128P6Q-A)
100-pin 0.65-mm-pitch QFP
(100P6S-A)
100-pin 0.5-mm-pitch LQFP
(100P6Q-A)
Required according to a foot
pattern of a target system
80-pin 0.65-mm-pitch QFP
(80P6S-A)
M3062PT-80FPB
M3T-F160-128NRD
