6
B+/GND
Power
Connector
LED Power
Indicator
REM
Connector
Four (4) custom, round, hex screws included in the acces-
sory pack hold the unit in place. These screws are covered
when the end caps are installed.
The Punch 4-Channel is turned on by connecting the blue
remote turn-on wire to the source unit’s “Accessory” or
“Auto Antenna” lead, either of which will go to +12 volts
when the source unit is turned on.
The LED illuminates when the unit is activated.
These connectors are used to supply power and ground
to the amplifier and accept 12 gauge - 8 gauge wire.*
These gold-plated terminal blocks connect the Right/Left
Front and Right/Left Rear channel outputs to the speak-
ers and accept wire sizes from 8 gauge through 18 gauge.
Gold-plated connectors are immune to corrosion that can
cause signal deterioration.
Mounting
Screws
Power/REM/LED Side
*Rockford Fosgate's Perfect Interface line of accessories in-
cludes high quality power and speaker wire, gold plated RCA
interconnecting cable and other products to complete your
installation. Ask your Authorized Rockford Fosgate Dealer about
Perfect Interface.
Speaker
Ouptut
Terminals
LED
Indicator
B+/GND
Power Connectors
REM
Connector
Front Speaker
Output Terminals
Rear Speaker
Output Terminals
