22
4-CHANNEL WITH BRIDGED SUBWOOFER
• Allows front to rear fading
• Sub-woofer is optional
• Sub-woofer can be bridged on front or rear or both
– +
– +
Input switch set to Rear
Front crossover set to Full Range
Rear crossover set to Full Range
Front+Rear summed output not used
Phase switch set to 0
°
+ R I G H T –
REM B+ GND
+ L E F T –
REAR
(bridge)
+ R I G H T – + L E F T –
FRONT
(bridge)
4 Ω (2 Ω min.)
Mid Range/
Tweeter
4
Ω
Subwoofer
– +
TREBLE GAIN BASS
FRONT
FRONT FRNT+REAR REAR
OUT IN IN
R
L
R
L
TREBLE GAIN BASS
REAR
0 180 R F
PHASE INPUT
– +
Full Range
– +
Full Range
SOURCE UNIT
4
Ω
(2
Ω
min.)
Mid Range/
Tweeter
