Bi-amplified stereo – Rockford Fosgate 4-CHANNEL AMPLIFIER User Manual
Page 24
21
–
+
–
+
4 Ohm (2
Ω
min.)
Mid Range/
Tweeter
Input switch set to F
Front crossover set to 100 Hz High Pass
Rear crossover set to 100 Hz Low Pass
Front+Rear summed output not used
Phase switch set to 0
°
+ R I G H T –
REM
B+ GND
+ L E F T –
REAR
(bridge)
+ R I G H T –
+ L E F T –
FRONT
(bridge)
Subwoofer
–
+
–
+
Subwoofer
4 Ohm (2
Ω
min.)
Mid Range/
Tweeter
SOURCE UNIT
TREBLE GAIN
BASS
FRONT
FRONT
FRNT+REAR
REAR
OUT
IN
IN
R
L
R
L
TREBLE GAIN
BASS
REAR
0
180 R
F
PHASE
INPUT
BI-AMPLIFIED STEREO
*
Always start with the phase switch on 0
°
, then switch to 180
°
and listen.
Select the position that provides the best frequency response.
*
